Hytera

DMR Tier II conventional,AMBE+2,Hytera

Hytera PD785 Frequency Range: UHF1: 400-470MHz; UHF2: 450-520MHz; UHF3: 350-400MHz; UHF5: 806-825MHz (transmit only) 851-870MHz (transmit + receive) 896-902MHz (transmit only) 935-941 MHz (transmit + receive); VHF 1: 136-174 MHz; VHF 3: 210-270 MHz Channel capacity: 1024 Area capacity: 64 Channel Spacing: 25/20/12.5KHz Operating voltage: 7.4V (rated value) Dimensions (H×W×D) mm: 125×55×37 Weight: 355g Display: LCD screen: 160×128 pixels, 65536 colors, 1.8 inches, 6 lines

Hytera MD788G Description Frequency Range: UHF: 400-470MHz, 450-520MHz, 350-400MHz, 806-941MHz, VHF: 136-174MHz, 210-270MHz Channel Capacity: 1024 Zone Capacity: 64 each with a maximum of 256 channels Weight: 1.7kg Dimensions: 60x174x200mm

Port: Guangzhou, China Brand: Hytera Model: HP780 Frequency range: UHF3: 350~400MHz UHF1: 400~470MHz VHF: 136~174MHz Channel capacity: 1024 Area Capacity: 64 Working voltage: 7.7V (rated) Battery: 2400 mAh Li-polymer anti-counterfeiting battery Average battery working time: (5/5/90 duty cycle, high power transmission) Without GPS: 24 hours / With GPS: 20 hours (digital mode) Display: LCD display: 240x320, 262000 colors, 2.4 inches, 10 lines Environmental indicators: Operating temperature range: -30℃～+60℃ Storage temperature range: -40℃～+85℃ Dustproof and waterproof: IEC60529-IP68

430-470MHzDMR Tier II conventional,AMBE+2,Hytera

136-174MHzAnalogue conventional only 400-470MHZAnalogue conventional only

Hytera Polymer Battery Pack Model: BP401011CPSU39T Nominal Voltage: 3.85V Charging Limit Battery: 4.4V Rated Capacity: 4000mAh/15.4Wh Warning: Please do not disassemble, puncture, short-circuit or throw the battery into a fire. It is forbidden to use the battery after it is flooded with water! Do not place it in a high dust environment above 609C! If the battery bulges severely, do not continue to use it 305279927404D24DQA1916Zhe Nengda Communications Co., Ltd. AP510

Port: Guangzhou, China Brand: Hytera Model: HR1060 Frequency range: UHF1:400-470MHz /VHF:136-174MHz Channel capacity: 64 Channel Spacing: 12.5kHz/20kHz/25kHz Working voltage: DC: 13.6V / AC: 100V-240V Current consumption (standby): DC: ≤0.9A / AC: ≤0.35A Current consumption (transmission): DC: ≤12A / AC: ≤1.2A Antenna Impedance: 50Ω Frequency stability: ≤±0.5ppm Duty cycle: 100% Dimensions (W×H×D) mm: 44 x 483 x 366 mm Weight: 8kg RF output power: 5-50W (continuously adjustable) FM modulation mode: 11K0F3E@12.5kHz /16K0F3E@25kHz 4FSK digital modulation method: 12.5kHz data only: 7K60FXD 12.5kHz data and voice: 7K60FXW Conducted/radiated emissions: Working: -36dBm≤1GHz,-30dBm>1GHz Standby: -57dBm≤1GHz,-47dBm>1GHz Modulation limit: ±2.5kHz@12.5kHz / ±5.0kHz@25kHz FM hum and noise: 40dB@12.5kHz /45dB@25kHz Adjacent channel power: 60dB@12.5kHz /70dB@25kHz Audio Response: +1 ~ -3dB Audio Distortion: ≤3% Digital Vocoder Type: AMBE+2™/NVOC Digital protocol: ETSI-TS102 /361-1,-2,-3 Sensitivity (analog): 0.22μV (12dB SINAD) 0.18μV (typ): (12dB SINAD) Sensitivity (digital): 0.22μV/BER5% Adjacent channel selectivity: 65dB@12.5kHz/75dB@25kHz (TIA_603) 60dB@12.5kHz/70dB@25kHz (ETSI) Intermodulation: 75dB@12.5kHz/25kHz (TIA_603) 70dB@12.5kHz/25kHz (ETSI) Spurious Response Suppression: 80dB@12.5kHz/25kHz (TIA_603) 80dB@12.5kHz/25kHz (ETSI) Blocking: 90dB Hum and Noise: 40dB@12.5kHz /45dB@25kHz Rated audio distortion: ≤3% Audio response: +1～-3dB Conducted emission spurious: ≤-57dBm(≤1GHz) /≤-47dBm(>1GHz) Operating temperature range: -30℃～+60℃ Storage temperature range: -40℃～+85℃ Humidity: Per MIL-STD 810/≤ +65℃, 95%RH

DMR Tier II conventional

Hytera power adapter model S010WC0500200PIN: PS2022 input 100-240V~output 55O/60H20.4AEM204 made in China H352F AP510

Brand: Hytera Model: PS22002 Name: External power supply (220-12V for MD7) Input voltage: 90V-264V Maximum input current: 5A Working frequency: 47Hz-63Hz Battery Type: 12V Battery capacity: ≥40AH Output voltage: 13.8V±2% Maximum output current: 16A Output voltage ripple: <150mV Overcurrent Protection: 17A-23A Overvoltage protection: 15.0V-18.2V Constant current charging: 1000±100mA Fan: Noise <45dB

GPS,built-in BT,DMR Tier II conventional,AMBE+2,Hytera
